- New
A Furuno FCV 600-L Fishing Radar in good condition
€250.00
Furuno FCV-600L in perfect working order. > The set includes the screen, its mounting bracket and its protective cover. Note that it is sold alone, without probe or additional cables. Thanks to its TrueEcho CHIRP™ technology and its ultra-bright 5.7” screen, this compact fishfinder guarantees precise and reliable detection of the seabed, even in direct sunlight.
GENERAL
CW frequency
CHIRP frequency
DISPLAY
FCV-600: 5.7" (640x480 VGA - 1,000 cd/m2)
Display: Single Frequency, Dual Frequency, Zoom, Nav Data, A-Scope, Zoom Marker, Bottom-Lock, Bottom Discrimination, Color Gamut Extension, ACCU-FISH™, RezBoost™
Languages: English, French, Spanish, German, Italian, Portuguese, Greek, Polish, Danish, Swedish, Norwegian, Finnish, Chinese, Japanese, Thai, Vietnamese, Indonesian, Myanmar (Burmese)
Basic scale: 2 - 1200 m*
*m, ft, fm, HR, pb can be selected from the menu
Alarm: Bottom, fish (normal), ACCU-FISH™, fish (B/L), Bottom discrimination, Fish level, Temperature, Speed, Arrival and Battery.
Scale offset: Up to 1200m
Extension range: Bottom extension: 2 - 10 m and Section extension: 2 - 1,200 m
Image advance speed: 8 steps: stop, 1/16, 1/8, 1/4, 1/2, 1, 2, 4
Pulse length and PRR: 0.04 to 3.0 ms, Max 3000 pulses/min
Interface (IEC61162-1, NMEA0183 Ver 1.0/2.0/3.0, NMEA2000):
NMEA0183 sentences (FCV-800 only)
Input: BWC, GGA, GLL, GNS, HDG, HDT, MDA, MTW, MWV, RMA, RMB, RMC, THS, VHW, VTG, XTE, ZDA
Output: DBS, DBT, DPT, MTW*, RMB*, VHW*, TLL* by key operation
*External data required
NMEA2000 phrases
Entry: 059392, 059904, 060160, 060416, 060928, 061184, 065240, 065280, 126208, 126720, 126996, 127250, 127252, 127257,
128259, 129025, 129026, 129029, 129283, 129284, 130306, 130310, 130311, 130312, 130314, 130316, 130577, 130821
Output: 059392, 059904, 060928, 061184, 126208, 126464, 126720, 126993, 126996, 126998, 128259, 128267, 130310, 130312,
130316, 130821, 130822, 130830, 130831, 130832
ENVIRONMENT
Temperature: -15°C to +55°C
Waterproofing: IP56
FOOD
FCV-600: 12-24 V: 1.0 - 0.6 A
LIST OF EQUIPMENT
Standard:
1. Display unit with bracket
2. Standard installation materials and spare parts
Options:
1. Probe: To be specified when ordering
2. Speed/temperature sensor: ST-02MSB, ST-02PSB, T-04MSB, T-04MTB
3. Connection kit for connecting the speed and temperature sensor or the temperature sensor
4. NMEA power cable
5. Recessing kit: OP02-89 - FCV-600 / OP02-88 - FCV-800
6. Adapter cable for FCV-800 - dual band CHIRP 1kW FRU-MJ10CCB12-300
R2657
1 Item
Used
